ØFeature:
l360° full-angle scanning, up to 50m,
lCompatible with reflector navigation and natural navigation, and suitable for application requirements of hybrid navigation,
lHighly reliable motor design: cope with high-speed and bumpy operating environments,
lAngular resolution:up to 0.06°,
lHorizontal plane error±0.5°to ensure horizontal scanning distance,
l60k/s point cloud density: provide azimuth, distance, reflection strength,
lCertication: FCC,EMC,CE,RoHS,REACH,FDA,
lIP66 Protection Level
ØApplication scenarios:
LR-1F is also suitable for applications in various industrial scenarios, such as robotics, security and surveillance, industrial automation and logistics, etc., and can also be used for spatial surveying and mapping systems such as mobile surveying and mapping. Users can choose according to the functional requirements of environmental perception and navigation Our different versions.
Num | File name | File type | File layout | Update time | Operate |
1 | LR-1F - datasheet_EN | document | 2024-04-16 | Download | |
2 | LR-1F- QuickStartUseManual_EN | document | 2024-04-16 | Download | |
3 | LR-1F- User Manual_EN | document | 2024-04-16 | Download | |
4 | LR-1BS/LR-1F - Communication Data Protocol_EN | document | 2024-04-16 | Download |
Num | File name | File type | File layout | Update time | Operate |
1 | 2D Lidar ResetConfig | Software | rar | 2022-07-12 | Download |
2 | Olamview(x64) | Software | zip | 2024-04-16 | Download |
3 | 2D Lidar Ros Driver | Software | rar | 2022-07-12 | Download |
Num | File name | File type | File layout | Update time | Operate |
1 | LR-1F- Certification Report (EMC test report) _EN | Certificate | 2022-06-17 | Download | |
2 | LR-1F- Certification Report (EMC-CE CERT) _EN | Certificate | 2022-06-17 | Download | |
3 | LR-1F- Certification Report (FCC) _EN | Certificate | 2022-06-17 | Download | |
4 | LR-1F- Certification Report (FDA) _EN | Certificate | 2022-06-17 | Download | |
5 | LR-1F- Certification Report (Laser Safety IEC60825) _EN | Certificate | 2022-06-17 | Download | |
6 | LR-1F- Certification Report (LGS-N50 ReachSVHC 209) _EN | Certificate | 2022-06-17 | Download | |
7 | LR-1F- Certification Report (LGS-N50 RoHS) _EN | Certificate | 2022-06-17 | Download | |
8 | LR-1F- Certification Report (Reach-SVHC 209) _EN | Certificate | 2022-06-17 | Download | |
9 | LR-1F- Certification Report (RoHS) _EN | Certificate | 2022-06-17 | Download | |
10 | LR-1F- Certification Report (Vibration and shock test report) _EN | Certificate | 2022-06-17 | Download |
Num | File name | File type | File layout | Update time | Operate |
1 | LR-1F - CAD Drawings_EN | DesignDrawing | zip | 2024-04-16 | Download |
